CS-Mini Capsule Separating Machine High Speed Powder Taking Machine
About us
Suzhou Halo Pharmatech Co. Ltd was established in June of 2006, a manufacturer who sees innovation and originality as living principles.
In last ten years, we have been focusing on researching, manufacturing and selling quality control equipment for pharmaceutical entrepreneurs and devoting ourselves to helping users reaching a new level of pharmaceutical quality control: automationized, informationized, intelligentized and internetized production process.
We are committed to help users solving problems in on-line testing and controlling of pharmaceutical production with different dosage forms to facilitate their management system. Our products: CVS (automatic capsule filling deviation monitoring machine), CMC (automatic capsule metage classifying machine), ECS (capsule on-line weighing and sorting machine) and CS (automatic vacuum decapsulator) are innovative in the world.
●Actual Use of Decapsulator
The following situation will cause abnormal capsule,it is need to use DECAPSULATOR to recycle powder:
1.At start-up stage of each batch of drug production,it is easy to appear instable filling of powder during debugging of Capsule Filling Machine,they are unqualified while the product can not meet the requirement with powder filling leve.
2.During daily production of pharmaceutical enterprises,the unqualified capsule products is caused by abnormal operation of relevant devices.
3.During daily production of pharmaceutical enterprises,the unqualified capsule products is caused by abnormal raw materials or unstable production process.
4.Additionally,the research institute of new medicine will also have some capsule products that failed to meet the expected requirements and needs to be improved further during small scale test stage of new drug to group for formula.
5.Simultaneously,with increasing higher requirements to quality,more and more enterprises will import automation equipment used for determination of weigh&quality of capsule products in its own process,so there will be more unqualified capsule products to have the opportunity to be filtered
●Advantages of Decapsulator
• Pure powder reclaiming, no shattered shells.
• Almost 100% capsule open rate.
• Save time and waste.
• Deal with abnormal capsules in a high speed.
• Cause absolutely no harm to power/pellets/tablets inside the capsule.
• Applicable to any sized capsules.
• Air is the only contact material with powder; no contamination.
• Usable capsule shells after separation.
• Convenient to operate, place and maintain.
●Performance of Decapsulator
| CS Model Technical Specifications |
| Model | CS-mini | CS1 | CS2 | CS3 | CS3-A | CS5 |
| Max Efficiency | 500caps/min | 700caps/min | 3000caps/min | 1000caps/min | 1000caps/min | 5000caps/min |
| Applicable Range | 000#, 00#, 0#, 0el, 1#, 2#, 3#, 4#, 5# and other hard capsules |
| Mode | Semi-auto | Semi-auto | Semi-auto | Auto | Auto | Auto |
| Sieving | Manual | Manual | Manual | Auto | Auto | Auto |
| Working Voltage | AC100-240V 50-60HZ |
| Power Rating | 35W | 35W | 35W | 60W | 60W | 120W |
| Chamber Capacity | 1.7L | 1L | 7.5L | 2.3L | 2.3L | 8.5L |
| Dimensions(mm) | 607×310×553 | 450×600×650 | 840×420×490 | 500×400×1550 | 500×400×1550 | 650×700×1700 |
| Weight | 45kg | 55kg | 80kg | 80kg | 80kg | 150kg |
| Operation Style | Buttons | Buttons | Buttons | Buttons | Touch Screen | Touch Screen |
For more information,please click the link below where we uploaded the relevant video on Yu Tube
http://www.capsuleweightchecker.comhttps://youtu.be/d32E6t8dOkE
